SATCO/NUVO 2X4 LED Backlit Flat Panel Wattage/CCT Selectable 30W/40W/50W 3500K/4000K/5000K Emergency Battery Backup 120-277V White (65-1666)

SATCO/NUVO 2X4 LED Backlit Flat Panel Wattage/CCT Selectable 30W/40W/50W 3500K/4000K/5000K Emergency Battery Backup 120-277V White (65-1666)

SKU 65-1666
by SATCO/NUVO
$177.99 - $177.99
$177.99
Backorder: Usually Ships in 7-14 Days
Product Description

A 2x4 LED backlit flat panel with integrated emergency battery backup — the workhorse format for code-driven commercial projects where every drop-ceiling fixture also needs to function as egress lighting.

Step the panel between 30W, 40W, and 50W as the project requires, and pick from three CCT options to match the rest of the building. The integrated battery takes over automatically on power loss to keep the space illuminated. Universal 120V–277V voltage and 0–10V dimming round out the spec.

Features

  • 2ft x 4ft rectangular LED backlit flat panel with integrated emergency battery backup
  • Selectable wattage: 30W / 40W / 50W
  • Selectable lumens: 3,750 / 4,500 / 6,250 lm
  • Selectable CCT: 3500K / 4000K / 5000K, 80+ CRI
  • 120V–277V universal voltage, 0–10V dimming
  • 50,000-hour rated life, 120° beam angle
  • Built-in 2KV surge protection, <20% THD, 0.9 power factor
  • Die-cast aluminum housing, white finish, polystyrene lens

Ideal For: Egress Corridors • Open Offices • Schools • Healthcare Spaces • Public Buildings

Integrated LED — no separate lamp required. IP20, damp location rated. cULus listed, DLC qualified, FCC compliant, ROHS compliant, Title 20 listed. CA Prop 65: Lead. Indoor use only.

Frequently Asked Questions
How bright is this product?
This product offers 3750/4500/6250 Selectable lumen options and features variable output allowing the brightness level to be adjusted for greater flexibility.
What color temperature is this product?
This product offers 3500-5000 Selectable color temperature options, allowing you to adjust the light output to your preferred tone from the available settings.
What voltage does this product operate on?
This product operates on 120V-277V and is compatible with a wide range of standard residential and commercial electrical systems. Always consult with an electrician regarding your specific voltage requirements.
Is this product dimmable?
This product is dimmable allowing the light output to be adjusted when used with a compatible dimmer. Make sure to confirm the dimmer's compatibility with the manufacturer.
Can this product be used in damp or outdoor locations?
This product is damp location rated meaning it can be used in areas exposed to humidity or light moisture such as covered outdoor areas or bathrooms. It should not be exposed to direct water.
What is the beam angle of this product?
This product has a 120-degree beam angle, delivering a wide, directional spread of light for broad area illumination.
What is the CRI and how does it affect light quality?
This product has a CRI of 80, delivering good color accuracy with natural, balanced color rendering. Colors will appear clear and consistent under this light.
