Product Description
This large ALED area light pairs a Type III distribution with field-selectable 300, 345, and 385-watt settings, mounting on a universal arm to replace 1,500-watt metal halide pole heads across parking lots, roadways, car dealerships, and large commercial sites. At 5000K it produces cool, bright white light suited to parking, security, and specification work, runs on 480V with 0-10V dimming standard, and the die-cast aluminum housing comes in black to match standard RAB pole hardware.
The universal arm covers hole patterns from 1 to 3 inches on center and includes a round-pole adapter plate, so the fixture slides and locks onto existing square or round poles without hardware swaps. Field-adjustable wattage delivers up to 47,596 lumens at the 385-watt step, 42,801 lumens at 345 watts, or 39,838 lumens at 300 watts, so one SKU dials three photometric levels across a site without ordering different fixtures per pole.
Features
-
Wattage: 300W, 345W, or 385W field-selectable (factory default 385W)
-
Light Output: 47,596 / 42,801 / 39,838 lumens at 385W / 345W / 300W
-
Equivalent: 1,500W metal halide
-
Color Temperature: 5000K
-
CRI: 84-85 CRI
-
Distribution: Type III (projects outward along the long edge of a lot or roadway)
-
Mounting: Universal arm, 1" to 3" center-to-center hole spacing, round-pole adapter plate included
-
Voltage: 480V
-
Dimming: 0-10V, down to 10%
-
Surge Protection: 10 kV line-to-line, 6 kV line-to-ground
-
Housing: Die-cast aluminum with polycarbonate lens and high-temperature silicone gaskets
-
Finish: Black
-
Lifespan: 100,000 hours (L70)
Ideal For: Parking Lots • Car Dealerships • Roadways • Service Drives • Large Commercial Sites
UL Listed and suitable for wet locations. IP66 rated against dust and water ingress. Cold-weather start to –40°F, maximum ambient 104°F. 3G vibration rated per ANSI C136.31.
