RAB ALED Field Adjustable Area Light 78W/90W/150W Type II 3000K 480V Pole Mount Black (ALEDM2TYB/480)

RAB ALED Field Adjustable Area Light 78W/90W/150W Type II 3000K 480V Pole Mount Black (ALEDM2TYB/480)

SKU ALEDM2TYB/480
by RAB
$1,050.00 - $1,050.00
$1,050.00
Backorder: Usually Ships in 4-7 Days
Product Description

This ALED area light mounts to a pole on a universal arm bracket, delivering broad, controlled illumination for parking lots, roadways, and outdoor work areas. The Type II distribution produces a long, narrow beam pattern designed for lighting roadside applications like perimeter drives, bike paths, and walkways.

The 3000K warm white output softens the visual impact on adjacent buildings and residential neighbors, and this SKU is Dark Sky approved for installations where light-pollution ordinances apply. The 480V driver suits large commercial and industrial sites where 480V service is already run to the pole, cutting the conductor size needed for long feeder runs. Field-adjustable output lets one SKU cover 150W, 90W, or 78W targets, so a single stocked fixture handles a range of pole heights and light-level requirements. The black finish blends with a dark metal pole or a contemporary building facade.

Features

  • Wattage (Field-Adjustable): 150W / 90W / 78W, factory set to 150W (replaces a 400-watt metal halide)
  • Color Temperature: 3000K warm white
  • Lumens (150W / 90W / 78W): 18,366 / 12,174 / 10,046
  • Efficacy: 126.5 to 133.8 lumens per watt across the wattage range
  • CRI: 82
  • Distribution: Type II (long, narrow beam for roadside applications)
  • Voltage: 480V
  • Dimming: 0-10V, down to 10% (requires a separate 0-10V dimming circuit)
  • Mounting: Universal arm bracket fits pole hole spacing from 1" to 5-1/2" center to center; round pole adapter included
  • Finish: Black, high-durability powder coat formulated for long-term outdoor color retention
  • Housing: Die-cast aluminum with polycarbonate lens
  • Cold-Start Temperature: -40°F
  • Surge Protection: 10 kV line-to-line, 6 kV line-to-ground
  • Vibration Rating: 3G per ANSI C136.31
  • IP Rating: IP66 (dust and water)
  • Rated Life: 100,000 hours (L70)

Ideal For: Parking Lot Perimeters • Roadways • Bike Paths • Walkways • Service Drives • Loading Areas

UL Listed and suitable for wet locations. Dark Sky approved for installations governed by light-pollution ordinances.

Frequently Asked Questions
How bright is this product?
This product offers 10046/12174/18366 Selectable lumen options and features variable output allowing the brightness level to be adjusted for greater flexibility.
What color temperature is this product?
This product has a color temperature of 3000K, providing soft white light that maintains warmth while delivering clear, comfortable illumination.
What is the CRI and how does it affect light quality?
This product has a CRI of 82, delivering good color accuracy with natural, balanced color rendering. Colors will appear clear and consistent under this light.
