Product Description
This large ALED area light mounts on a universal pole arm to cast broad, controlled Type III light across parking lots, roadways, and open commercial yards. It runs on 260 watts and puts out 37,434 lumens, with field-adjustable settings that let an installer step the output down to 220 watts (33,140 lumens) or 170 watts (25,663 lumens) at commissioning to match pole spacing and site loads.
The die-cast aluminum housing comes in bronze, formulated for long-lasting color, and stays sealed with high-temperature silicone gaskets and a polycarbonate lens against water and dust. Efficacy reaches 150.6 lumens per watt at the 170-watt step, and the Type III distribution pushes the pool of light outward from the pole to fill parking bays, drive lanes, and general illuminated areas. Sized to replace a 1,000-watt metal halide fixture. The universal mounting arm accepts hole spacing patterns from 1 inch to 3 inch center to center, and a round-pole adapter plate ships in the box.
Features
- 260W / 220W / 170W field-adjustable output, factory default 260W
- 37,434 / 33,140 / 25,663 lumens at 5000K cool white, 84-85 CRI
- Type III distribution for parking-lot and roadway coverage from a pole
- 480V input, 0-10V dimming standard, dims to 10%
- 10 kV line-to-line / 6 kV line-to-ground surge protection
- Die-cast aluminum housing, polycarbonate lens, bronze finish
- Universal mounting arm, 1" to 3" hole spacing, round-pole adapter plate included
- 100,000-hour L70 LED life
Ideal For: Parking Lots • Roadways • Retail Centers • Commercial Yards • School Campuses
UL Listed for wet locations, IP66-rated against dust and water. Rated for cold-weather starting to -40°F and operation at up to 104°F ambient. 3G vibration rating per ANSI C136.31.
