Understanding LED Tube Types: Type A, Type B, Type A+B and Type C

When upgrading from fluorescent lighting to LED tubes, one of the most important decisions is choosing the correct tube type. While all LED tubes provide the benefits of improved energy efficiency, longer life and reduced maintenance, they are not installed the same way.

The four most common LED tube categories are Type A, Type B, Type A+B and Type C. Understanding how each one receives power and interacts with the fixture can help you select the best option for your application.

What Is an LED Tube Driver?

Before looking at each tube type, it helps to understand the role of the driver.

A driver regulates the electrical power supplied to the LEDs, similar to how a ballast operates in a fluorescent system. Depending on the tube type, the driver may be located:

• Inside the LED tube
• In an existing fluorescent ballast
• In a separate external driver

The location of the driver is what separates Type A, Type B, Type A+B and Type C tubes.

Type A LED Tubes

Type A LED tubes contain an LED driver that is able to use a ballast for power and often can work with the ballast that is currently in the fixture. These are sometimes called ballast-compatible or plug-and-play tubes.

Because they utilize the existing ballast, Type A tubes are typically among the easiest LED retrofits to install. In many cases, the fluorescent lamps can simply be removed and replaced with LED tubes without modifying the fixture wiring.

Advantages of Type A Tubes

• Quick and simple installation
• No fixture rewiring required
• Reduced labor costs
• Ideal for large facilities looking for a fast upgrade


Considerations

Although installation is straightforward, the ballast remains part of the system. Since ballasts eventually fail, maintenance may still be required in the future. Additionally, compatibility between the LED tube and the existing ballast should always be verified before installation.

Type B LED Tubes

Type B LED tubes, often called ballast bypass, will not work with a ballast and will need to be directly wired to the power source. These tubes contain their own integrated driver.

With a Type B retrofit, the ballast is removed or disconnected and power is supplied directly to the lamp sockets according to the manufacturer's wiring instructions.

Advantages of Type B Tubes

• Eliminates ballast maintenance and replacement costs
• Greater system efficiency because power is not passing through a ballast
• Simplified long-term maintenance
• Popular choice for permanent LED conversions

Considerations

Type B installations require rewiring the fixture, which generally increases installation time and may require a qualified electrician. Proper wiring procedures must be followed to ensure safety and compliance.

For many facility managers, the extra installation effort is worthwhile because removing the ballast eliminates one of the most common points of failure in a fluorescent fixture.

Type A+B LED Tubes

There are also Type A and B tubes, which can potentially work both ways, either using the fixture’s existing ballast or rewiring the fixture directly to the power source and utilizing the internal driver in the tube.

These hybrid tubes provide flexibility during installation and future maintenance.

Advantages of Type A+B Tubes

• Can operate with a compatible ballast initially
• Can later be converted to ballast bypass operation
• Flexible solution for phased upgrades
• Helps reduce concerns about future ballast failures

Many facilities choose Type A+B tubes when they want a simple installation today but also want the option to remove the ballast later without replacing the lamps.

Considerations

Not every ballast will be compatible, so checking manufacturer compatibility lists remains important. Installation instructions should also be reviewed carefully when converting from ballast-compatible operation to ballast-bypass operation.

Type C LED Tubes

A final option are Type C LED tubes. These tubes use a remote driver, instead of the internal driver, similarly to how the fluorescent tube uses the ballast. Type C tubes can provide additional functionality, like dimming.

Instead of housing the driver inside the lamp, a Type C system uses an external LED driver installed within or alongside the fixture.

Advantages of Type C Tubes

• Driver and lamp can often be serviced separately
• Can provide enhanced functionality such as dimming
• Often delivers high system performance and efficiency
• Suitable for advanced commercial lighting projects


Considerations

Type C systems typically require more planning and installation work than Type A or Type B retrofits. However, they can offer greater control and flexibility, especially in commercial environments where lighting controls are important.

Comparing the Four LED Tube Types

Which LED Tube Type Is Right for You?

The best choice depends on your goals:

• Choose Type A if you want the quickest, easiest retrofit with minimal fixture modifications.
• Choose Type B if you want to eliminate ballast maintenance and maximize long-term simplicity.
• Choose Type A+B if you want installation flexibility and future-proofing.
• Choose Type C if you need advanced features such as dimming, enhanced control capabilities, or serviceable drivers.

By understanding how each LED tube type receives power and how it interacts with the fixture, you can select a retrofit solution that balances installation cost, maintenance requirements, and long-term performance.
